Food-grade SUS304/SUS316L single-layer storage tank for temporary holding and mixing of milk, juice, syrup and other liquids. Optional agitation, CIP-ready, with sanitary fittings for dairy, beverage and food plants.
For plants that need dependable, hygienic holding of liquid product between processing steps, the DG Series single-layer stainless steel tank is a workhorse choice. Widely used across dairy, beverage, brewing and food operations in Central Asia, Africa, Southeast Asia and South America, it provides clean temporary storage and gentle mixing without the cost of an insulated jacket — ideal where temperature holding is not required.
Construction & Options
- Material: fully SUS304-2B or SUS316L stainless steel, cylinder wall 3–4mm thick.
- Structure: single-layer cylindrical body on triangular or cylindrical support legs.
- Agitation choice: supplied with or without an agitator — paddle, anchor, propeller and other types available to match the product.
Standard Fittings
- Closed manhole and insect-proof breathable air cap
- PT100 digital thermometer and CIP cleaning ball
- Material inlet/outlet ports and sampling valve
- Lever valve and adjustable triangular support legs
Technical Parameters
| Model | Effective Volume (L) | Cylinder Size (mm) | Total Height (mm) | Plate Thickness (mm) | Inlet/Outlet Diameter (mm) |
|---|---|---|---|---|---|
| DG-600 | 600 | 900×1000 | 1950 | 3 | φ38 / φ51 |
| DG-1 | 1000 | 1150×1000 | 1950 | 3 | φ38 / φ51 |
| DG-1.5 | 1500 | 1160×1500 | 2450 | 3 | φ38 / φ51 |
| DG-2 | 2000 | 1400×1220 | 2350 | 3 | φ38 / φ51 |
| DG-3 | 3000 | 1600×1500 | 2450 | 3 | φ38 / φ51 |
| DG-4 | 4000 | 1620×2000 | 2950 | 3 | φ38 / φ51 |
| DG-5 | 5000 | 1800×2000 | 2950 | 3 | φ38 / φ51 |
| DG-6 | 6000 | 1950×2000 | 2950 | 3 | φ38 / φ51 |
| DG-8 | 8000 | 2060×2400 | 3350 | 4 | φ65 / φ51 |
| DG-10 | 10000 | 2300×2400 | 3350 | 4 | φ65 / φ51 |
| DG-12 | 12000 | 2270×3000 | 3950 | 4 | φ65 / φ51 |
| DG-15 | 15000 | 2530×3000 | 3950 | 4 | φ65 / φ51 |
Data is for reference only. Specifications may change without prior notice due to continuous R&D improvement.
Applications
- Dairy: temporary storage and mixing of fresh milk and milk-based ingredients
- Beverage: holding and blending of juice, tea drinks and syrup
- Brewing: transfer and holding of beer, fruit wine and fermentation broth
- Food & chemical: liquid condiments, plant extracts, additives and process solutions
